WSP3312I UNIVERSAL COUNTER
BDT 153,164/-
Product Details
Brand: MCP
Model: WSP3312I
Country Of Origin: China
Features
-
Dual independent channels for simultaneous measurement and display
-
Time interval and phase difference measurement between Channel A and Channel B
-
High-performance AVR CPU, LSI, and CPLD for superior reliability
-
Positive/negative pulse width and rise/fall time measurement
-
Automatic statistical analysis for frequency measurement: mean, max, min, delta, absolute deviation, relative deviation (PPM), standard deviation, Allan variance
-
Average measurement function for enhanced accuracy of time interval, pulse width, phase, and duty cycle
-
Time gate totalizing and manual totalizing modes
-
Automatic data storage with zero loss
-
Save up to 9 measurement setups
-
Interfaces: USB, RS232, and continuous printer output
-
QVGA display with compact, elegant design and intuitive operation
Technical Data
| Specification | WSP53131 |
|---|---|
| Function | Frequency, Time Interval, Period, Frequency Ratio, Totalize, Duty Cycle, Phase, Self-calibration |
| Frequency Range | DC–225MHz (Channel A & B) |
| Channel C | 100MHz–1.5GHz (I), 100MHz–2.5GHz (II), 100MHz–3GHz (III), 100MHz–6GHz (IV) |
| Input Voltage | 30mVrms–1.5Vrms (<225MHz); 50mVrms–1.5Vrms (225MHz–1.5GHz); 30mVrms–1Vrms (1.5–6GHz) |
| Period Range | 4.44ns–1000s, 100ps resolution |
| Time Interval Range | –1ns–1000s, 100ps resolution |
| Single Shot Time Interval Resolution | 100ps |
| Phase Range | 0–359° |
| Pulse Width Range | ≥20ns (cycle <100s) |
| Duty Cycle Range | 1–99% (cycle <100s) |
| Frequency Resolution | 10 digits/s |
| LPF | 100kHz |
| Attenuator | ×1, ×10 |
| Trigger Mode | Rising/Falling edge |
| Trigger Level | –5V to +5V presettable |
| Coupling Mode | CH A/B: AC/DC; CH C: AC |
| External Time Base | 5MHz/10MHz auto-select |
| Input Impedance | 1MΩ/45pF or 50Ω |
| Totalize Capacity | 1×10¹⁰ |
| Time Base Stability | 5MHz, ≤1×10⁻⁷/day |
| Power Supply | 110–127VAC ±10%, 220–240VAC ±10%, 50/60Hz ±2Hz |
| Dimensions | 265×104×375mm |
| Weight | 2.5kg |
| Function | Frequency, Time Interval, Period, Frequency Ratio, Totalize, Duty Cycle, Phase, Self-calibration |
| Frequency Range | DC–225MHz (Channel A & B) |
| Channel C | 100MHz–1.5GHz (I), 100MHz–2.5GHz (II), 100MHz–3GHz (III), 100MHz–6GHz (IV) |
| Input Voltage | 30mVrms–1.5Vrms (<225MHz); 50mVrms–1.5Vrms (225MHz–1.5GHz); 30mVrms–1Vrms (1.5–6GHz) |
| Period Range | 4.44ns–1000s, 100ps resolution |
| Time Interval Range | –1ns–1000s, 100ps resolution |
| Single Shot Time Interval Resolution | 100ps |
| Phase Range | 0–359° |
| Pulse Width Range | ≥20ns (cycle <100s) |
| Duty Cycle Range | 1–99% (cycle <100s) |
| Frequency Resolution | 10 digits/s |
| LPF | 100kHz |
| Attenuator | ×1, ×10 |
| Trigger Mode | Rising/Falling edge |
| Trigger Level | –5V to +5V presettable |
| Coupling Mode | CH A/B: AC/DC; CH C: AC |
| External Time Base | 5MHz/10MHz auto-select |
| Input Impedance | 1MΩ/45pF or 50Ω |
| Totalize Capacity | 1×10¹⁰ |
| Time Base Stability | 5MHz, ≤1×10⁻⁷/day |
| Power Supply | 110–127VAC ±10%, 220–240VAC ±10%, 50/60Hz ±2Hz |
| Dimensions | 265×104×375mm |
| Weight | 2.5kg |
Features
-
Dual independent channels for simultaneous measurement and display
-
Time interval and phase difference measurement between Channel A and Channel B
-
High-performance AVR CPU, LSI, and CPLD for superior reliability
-
Positive/negative pulse width and rise/fall time measurement
-
Automatic statistical analysis for frequency measurement: mean, max, min, delta, absolute deviation, relative deviation (PPM), standard deviation, Allan variance
-
Average measurement function for enhanced accuracy of time interval, pulse width, phase, and duty cycle
-
Time gate totalizing and manual totalizing modes
-
Automatic data storage with zero loss
-
Save up to 9 measurement setups
-
Interfaces: USB, RS232, and continuous printer output
-
QVGA display with compact, elegant design and intuitive operation
Technical Data
| Specification | WSP53131 |
|---|---|
| Function | Frequency, Time Interval, Period, Frequency Ratio, Totalize, Duty Cycle, Phase, Self-calibration |
| Frequency Range | DC–225MHz (Channel A & B) |
| Channel C | 100MHz–1.5GHz (I), 100MHz–2.5GHz (II), 100MHz–3GHz (III), 100MHz–6GHz (IV) |
| Input Voltage | 30mVrms–1.5Vrms (<225MHz); 50mVrms–1.5Vrms (225MHz–1.5GHz); 30mVrms–1Vrms (1.5–6GHz) |
| Period Range | 4.44ns–1000s, 100ps resolution |
| Time Interval Range | –1ns–1000s, 100ps resolution |
| Single Shot Time Interval Resolution | 100ps |
| Phase Range | 0–359° |
| Pulse Width Range | ≥20ns (cycle <100s) |
| Duty Cycle Range | 1–99% (cycle <100s) |
| Frequency Resolution | 10 digits/s |
| LPF | 100kHz |
| Attenuator | ×1, ×10 |
| Trigger Mode | Rising/Falling edge |
| Trigger Level | –5V to +5V presettable |
| Coupling Mode | CH A/B: AC/DC; CH C: AC |
| External Time Base | 5MHz/10MHz auto-select |
| Input Impedance | 1MΩ/45pF or 50Ω |
| Totalize Capacity | 1×10¹⁰ |
| Time Base Stability | 5MHz, ≤1×10⁻⁷/day |
| Power Supply | 110–127VAC ±10%, 220–240VAC ±10%, 50/60Hz ±2Hz |
| Dimensions | 265×104×375mm |
| Weight | 2.5kg |
The WSP53131 Universal Counter delivers high-precision frequency and time measurements with dual independent channels for simultaneous operation. Supporting ranges up to 6GHz, it offers advanced statistical analysis including Allan variance and PPM deviation for comprehensive data evaluation. With 100ps resolution, AC/DC coupling, and selectable trigger levels, the WSP53131 ensures exceptional accuracy for laboratory, calibration, and RF testing applications. Compact and reliable, it features USB, RS232, and printer interfaces for seamless data management.
