SP1500A MULTI-FUNCTION COUNTER
BDT 17,018/-
Product Details
Brand: MCP
Model: SP1500A
Country Of Origin: China
Functions
-
Frequency measurement
-
Period measurement
-
Totalize
-
Self-calibration
Technical Data
| Specification | SP1500A | SP1500B | SP1500C | SP2500B | SP3000B | SP3000C |
|---|---|---|---|---|---|---|
| Frequency Range | 1Hz–1.5GHz | 1Hz–1.5GHz | 0.005Hz–1.5GHz | 1Hz–2.5GHz | 1Hz–3.0GHz | 0.005Hz–3.0GHz |
| Period Range | 10ns–1s | Same | Same | Same | Same | Same |
| Totalize Capacity | 10⁸–1 | Same | Same | Same | Same | Same |
| Sensitivity | 40mVrms (1–10Hz), 20mVrms (10Hz–100MHz), 30mVrms (100MHz–3GHz) | Same | Same | Same | Same | Same |
| Input Impedance | 1MΩ/40pF (CH A), 50Ω (CH B) | Same | Same | Same | Same | Same |
| Input Voltage | 20mVrms–250Vp-p (CH A), 30mVrms–1Vrms (CH B) | Same | Same | Same | Same | Same |
| Coupling Mode | AC | AC | AC/DC | AC | AC | AC/DC |
| Trigger Level | 0V | 0V | –2.5V to +2.5V | 0V | 0V | –2.5V to +2.5V |
| Measurement Error | ±Time base accuracy ±Trigger error × Measured frequency (or period) ±LSD | Same | Same | Same | Same | Same |
| Time Base Stability | ±5×10⁻⁵/day | Same | Same | Same | Same | ±1×10⁻⁶/day |
| Power Source | 110–127VAC ±10%, 220–240VAC ±10%, 50/60Hz ±2Hz | Same | Same | Same | Same | Same |
| Dimensions | 230×92×230mm | Same | Same | Same | Same | Same |
| Weight | 1.8kg | Same | Same | Same | Same |
| Frequency Range | 1Hz–1.5GHz |
| Period Range | 10ns–1s |
| Totalize Capacity | 10⁸–1 |
| Sensitivity | 40mVrms (1–10Hz), 20mVrms (10Hz–100MHz), 30mVrms (100MHz–3GHz) |
| Input Impedance | 1MΩ/40pF (CH A), 50Ω (CH B) |
| Input Voltage | 20mVrms–250Vp-p (CH A), 30mVrms–1Vrms (CH B) |
| Coupling Mode | AC |
| Trigger Level | 0V |
| Measurement Error | ±Time base accuracy ±Trigger error × Measured frequency (or period) ±LSD |
| Time Base Stability | ±5×10⁻⁵/day |
| Power Source | 110–127VAC ±10%, 220–240VAC ±10%, 50/60Hz ±2Hz |
| Dimensions | 230×92×230mm |
| Weight | 1.8kg |
Functions
-
Frequency measurement
-
Period measurement
-
Totalize
-
Self-calibration
Technical Data
| Specification | SP1500A | SP1500B | SP1500C | SP2500B | SP3000B | SP3000C |
|---|---|---|---|---|---|---|
| Frequency Range | 1Hz–1.5GHz | 1Hz–1.5GHz | 0.005Hz–1.5GHz | 1Hz–2.5GHz | 1Hz–3.0GHz | 0.005Hz–3.0GHz |
| Period Range | 10ns–1s | Same | Same | Same | Same | Same |
| Totalize Capacity | 10⁸–1 | Same | Same | Same | Same | Same |
| Sensitivity | 40mVrms (1–10Hz), 20mVrms (10Hz–100MHz), 30mVrms (100MHz–3GHz) | Same | Same | Same | Same | Same |
| Input Impedance | 1MΩ/40pF (CH A), 50Ω (CH B) | Same | Same | Same | Same | Same |
| Input Voltage | 20mVrms–250Vp-p (CH A), 30mVrms–1Vrms (CH B) | Same | Same | Same | Same | Same |
| Coupling Mode | AC | AC | AC/DC | AC | AC | AC/DC |
| Trigger Level | 0V | 0V | –2.5V to +2.5V | 0V | 0V | –2.5V to +2.5V |
| Measurement Error | ±Time base accuracy ±Trigger error × Measured frequency (or period) ±LSD | Same | Same | Same | Same | Same |
| Time Base Stability | ±5×10⁻⁵/day | Same | Same | Same | Same | ±1×10⁻⁶/day |
| Power Source | 110–127VAC ±10%, 220–240VAC ±10%, 50/60Hz ±2Hz | Same | Same | Same | Same | Same |
| Dimensions | 230×92×230mm | Same | Same | Same | Same | Same |
| Weight | 1.8kg | Same | Same | Same | Same |
The SP1500, SP2500, and SP3000 Series Multifunction Frequency Counters provide precise measurement of frequency, period, and totalize functions with built-in self-calibration. Covering ranges from 1Hz up to 3GHz, these counters are designed for both low-frequency and high-frequency applications. With selectable AC/DC coupling, adjustable trigger levels, and high sensitivity across wide ranges, they deliver reliable performance for laboratories, RF testing, and production environments. Compact and robust, the SP Series ensures accurate results with excellent time base stability.
