BR4822 LCR METER
BDT 57,253/-
Product Details
Brand: MCP
Model: BR4822
Country Of Origin: China
Features
-
BR5810: 100Hz–10kHz, four typical test frequency points
-
BR5812: 100Hz–100kHz, eight typical test frequency points
-
Large white backlight LCD display
-
Three test levels: 0.1V, 0.3V, 1.0V
-
Two source impedances: 30Ω, 100Ω
-
4-bin comparator and bin counter
-
RS232C and HANDLER interfaces
Technical Data
| Specification | BR5810 | BR5812 | ||
|---|---|---|---|---|
| Test Parameters | L/Q, C/D, R/Q | Z | /θ, C/R, L/R | |
| Accuracy | 0.1% | 0.1% | ||
| Test Frequencies | 100Hz, 120Hz, 1kHz, 10kHz | 100Hz, 120Hz, 1kHz, 10kHz, 20kHz, 30kHz, 60kHz, 100kHz | ||
| Test Levels | 0.1Vrms, 0.3Vrms, 1Vrms | Same | ||
| Output Impedance | 30Ω or 100Ω | Same | ||
| Measurement Ranges | Z | , R, X: 0.0001Ω–99.999MΩ; C: 0.001pF–99999µF; L: 0.001µH–99999H; D: 0.0001–9.9999; Q: 0.0001–9999.9; A%: –99.99%–99.99% | ||
| Measurement Speed | Slow: 2/s, Medium: 5/s, Fast: 12/s | Slow: 2/s, Medium: 8/s, Fast: 16/s | ||
| Equivalent Circuit | Series/Parallel | Same | ||
| Ranging Mode | Auto/Hold | Same | ||
| Trigger Mode | Internal/External, Manual | Same | ||
| Correction Functions | Open/Short, Sweep | Same | ||
| Display Mode | Direct, ΔABS, Δ% | Same | ||
| Display Digits | Primary/Secondary: 5 digits | Same | ||
| Comparator Functions | NG, P1, P2, P3, 4 bins | Same | ||
| Interfaces | RS232C, HANDLER | Same | ||
| LCD | Large white backlight | Same | ||
| Power Supply | 110–127VAC ±10% / 220–240VAC ±10%, 50/60Hz ±2Hz | Same | ||
| Dimensions | 320×140×360mm | Same | ||
| Weight | 3.5kg | Same |
| Test Parameters | L/Q, C/D, R/Q |
| Accuracy | 0.1% |
| Test Frequencies | 100Hz, 120Hz, 1kHz, 10kHz |
| Test Levels | 0.1Vrms, 0.3Vrms, 1Vrms |
| Output Impedance | 30Ω or 100Ω |
| Measurement Ranges | Z, R, X: 0.0001Ω–99.999MΩ; C: 0.001pF–99999µF; L: 0.001µH–99999H; D: 0.0001–9.9999; Q: 0.0001–9999.9; A%: –99.99%–99.99% |
| Measurement Speed | Slow: 2/s, Medium: 5/s, Fast: 12/s |
| Equivalent Circuit | Series/Parallel |
| Ranging Mode | Auto/Hold |
| Trigger Mode | Internal/External, Manual |
| Correction Functions | Open/Short, Sweep |
| Display Mode | Direct, ΔABS, Δ% |
| Display Digits | Primary/Secondary: 5 digits |
| Comparator Functions | NG, P1, P2, P3, 4 bins |
| Interfaces | RS232C, HANDLER |
| LCD | Large white backlight |
| Power Supply | 110–127VAC ±10% / 220–240VAC ±10%, 50/60Hz ±2Hz |
| Dimensions | 320×140×360mm |
| Weight | 3.5kg |
Features
-
BR5810: 100Hz–10kHz, four typical test frequency points
-
BR5812: 100Hz–100kHz, eight typical test frequency points
-
Large white backlight LCD display
-
Three test levels: 0.1V, 0.3V, 1.0V
-
Two source impedances: 30Ω, 100Ω
-
4-bin comparator and bin counter
-
RS232C and HANDLER interfaces
Technical Data
| Specification | BR5810 | BR5812 | ||
|---|---|---|---|---|
| Test Parameters | L/Q, C/D, R/Q | Z | /θ, C/R, L/R | |
| Accuracy | 0.1% | 0.1% | ||
| Test Frequencies | 100Hz, 120Hz, 1kHz, 10kHz | 100Hz, 120Hz, 1kHz, 10kHz, 20kHz, 30kHz, 60kHz, 100kHz | ||
| Test Levels | 0.1Vrms, 0.3Vrms, 1Vrms | Same | ||
| Output Impedance | 30Ω or 100Ω | Same | ||
| Measurement Ranges | Z | , R, X: 0.0001Ω–99.999MΩ; C: 0.001pF–99999µF; L: 0.001µH–99999H; D: 0.0001–9.9999; Q: 0.0001–9999.9; A%: –99.99%–99.99% | ||
| Measurement Speed | Slow: 2/s, Medium: 5/s, Fast: 12/s | Slow: 2/s, Medium: 8/s, Fast: 16/s | ||
| Equivalent Circuit | Series/Parallel | Same | ||
| Ranging Mode | Auto/Hold | Same | ||
| Trigger Mode | Internal/External, Manual | Same | ||
| Correction Functions | Open/Short, Sweep | Same | ||
| Display Mode | Direct, ΔABS, Δ% | Same | ||
| Display Digits | Primary/Secondary: 5 digits | Same | ||
| Comparator Functions | NG, P1, P2, P3, 4 bins | Same | ||
| Interfaces | RS232C, HANDLER | Same | ||
| LCD | Large white backlight | Same | ||
| Power Supply | 110–127VAC ±10% / 220–240VAC ±10%, 50/60Hz ±2Hz | Same | ||
| Dimensions | 320×140×360mm | Same | ||
| Weight | 3.5kg | Same |
The BR5810 and BR5812 LCR Meters deliver high-precision measurement of inductance, capacitance, resistance, quality factor, dissipation factor, and impedance. With selectable test frequencies up to 10kHz (BR5810) or 100kHz (BR5812), they provide flexibility for component characterization. Featuring a large backlit LCD, multiple test levels, and fast measurement speeds, these instruments are ideal for laboratories, R&D, and production testing. Built-in comparator and bin counter functions streamline quality control, while RS232C and HANDLER interfaces ensure easy integration.
