M10-QS1001 SINGLE OUTPUT ADJUSTABLE DC POWER SUPPLY
BDT 18,467/-
Product Details
Brand: MCP
Model: M10-QS1001
Country Of origin: China
Features
-
16 hours continuous output with full load
-
Over voltage protection
-
Voltage and current preset function
-
USB power output (5V/2A)
-
Constant voltage and constant current
-
Low ripple and noise
-
CV/CC auto switching
-
3‑digit LED display (4‑digit LED display optional)
Specifications
-
Line regulation:
-
CV ≤ 5×10−4+3 mV (M10‑QS30XX, M10‑QS60XX)
-
CV ≤ 1×10−4+3 mV (Other models)
-
CC ≤ 4×10−3+3 mA (M10‑QS30XX, M10‑QS60XX)
-
CC ≤ 2×10−3+3 mA (Other models)
-
-
Load regulation:
-
M10‑QS30XX, M10‑QS60XX:
-
CV ≤ 5×10−4+3 mV (≤10A)
-
CV ≤ 1×10−3+3 mV (>10A)
-
CC ≤ 4×10−3+3 mA
-
-
Other models:
-
CV ≤ 1×10−4+3 mV (≤3A)
-
CV ≤ 2×10−4+3 mV (3A–10A)
-
CC ≤ 1×10−3+3 mA (≤3A)
-
CC ≤ 2×10−3+3 mA (3A–10A)
-
-
-
Ripple & noise: CV ≤ 1.5mVrms, CC ≤ 3mArms
-
Display accuracy: ±(0.5%Rdg + 2 digits)
-
Input voltage: 110–127VAC ±10% 60Hz, 220–240VAC ±10% 50Hz (switchable)
| Line regulation: |
CV ≤ 5 × 10 − 4 + 3 mV (M10‑QS30XX, M10‑QS60XX) CV ≤ 1 × 10 − 4 + 3 mV (Other models) CC ≤ 4 × 10 − 3 + 3 mA (M10‑QS30XX, M10‑QS60XX) CC ≤ 2 × 10 − 3 + 3 mA (Other models) |
| Load regulation: |
M10‑QS30XX, M10‑QS60XX: CV ≤ 5 × 10 − 4 + 3 mV (≤10A) CV ≤ 1 × 10 − 3 + 3 mV (>10A) CC ≤ 4 × 10 − 3 + 3 mA |
| Other models: |
CV ≤ 1 × 10 − 4 + 3 mV (≤3A) CV ≤ 2 × 10 − 4 + 3 mV (3A–10A) CC ≤ 1 × 10 − 3 + 3 mA (≤3A) CC ≤ 2 × 10 − 3 + 3 mA (3A–10A) |
| Ripple & noise: | CV ≤ 1.5mVrms, CC ≤ 3mArms |
| Display accuracy: | ±(0.5%Rdg + 2 digits) |
| Input voltage: | 110–127VAC ±10% 60Hz, 220–240VAC ±10% 50Hz (switchable) |
Features
-
16 hours continuous output with full load
-
Over voltage protection
-
Voltage and current preset function
-
USB power output (5V/2A)
-
Constant voltage and constant current
-
Low ripple and noise
-
CV/CC auto switching
-
3‑digit LED display (4‑digit LED display optional)
Specifications
-
Line regulation:
-
CV ≤ 5×10−4+3 mV (M10‑QS30XX, M10‑QS60XX)
-
CV ≤ 1×10−4+3 mV (Other models)
-
CC ≤ 4×10−3+3 mA (M10‑QS30XX, M10‑QS60XX)
-
CC ≤ 2×10−3+3 mA (Other models)
-
-
Load regulation:
-
M10‑QS30XX, M10‑QS60XX:
-
CV ≤ 5×10−4+3 mV (≤10A)
-
CV ≤ 1×10−3+3 mV (>10A)
-
CC ≤ 4×10−3+3 mA
-
-
Other models:
-
CV ≤ 1×10−4+3 mV (≤3A)
-
CV ≤ 2×10−4+3 mV (3A–10A)
-
CC ≤ 1×10−3+3 mA (≤3A)
-
CC ≤ 2×10−3+3 mA (3A–10A)
-
-
-
Ripple & noise: CV ≤ 1.5mVrms, CC ≤ 3mArms
-
Display accuracy: ±(0.5%Rdg + 2 digits)
-
Input voltage: 110–127VAC ±10% 60Hz, 220–240VAC ±10% 50Hz (switchable)
The M10‑QS Series Single Output Adjustable DC Power Supply is a reliable and versatile solution for laboratories, universities, and industrial applications. Designed for continuous operation up to 16 hours at full load, it offers constant voltage and constant current modes with automatic CV/CC switching. Built‑in over voltage protection and USB output (5V/2A) add flexibility and safety. With low ripple and noise, precise regulation, and optional 4‑digit LED display, the M10‑QS Series is ideal for electronics testing, development, and educational environments requiring stable DC power.
